enFORCE DSP1500 SAN Unit Operation Manual
PAGE 4－21 (Rev. 4)
Chapter 4: System Setup and Wiring
4.7.5 Operation Timing Chart
OFF
STOP
ON
ON
READY
OFF
ON
RESET
OFF
ON
START
OFF
Condition Operating Operating
ON
BUSY
OFF
ON
ACCEPT
OFF
ON
REJECT
OFF
ON
ABNORMAL
OFF
WORK SELECT Parameter select fixed Parameter select fixed
0～4
ON
MANUAL
OFF
ON
START
OFF
ON
WORK SEL. 0
OFF
ON
WORK SEL.1
OFF
ON
WORK SEL.2
OFF
Condition
Home Position Search Home Position Return Advance Jog Return Jog
ON
BUSY
OFF
ON
READY
OFF
When the START signal turns on, BUSY turns ON and ACCEPT, REJECT and
READY signals turn OFF.
To start the Home-Position Search and Home-Position Return, set the START
signal ON for more than 20ms.
READY is not output while the MANUAL signal and START signal are ON.
MANUAL Mode
Automatic Mode
Timing to set the START signal
OFF, it is voluntary if the BUSY is
OFF.
Above 10ｍｓ
When the START or RESET signal
is turned ON the ACCEPT and
REJECT signals turn OFF.
Above 10ｍｓ
