enFORCE DSP1500 SAN Unit Operation Manual
(Rev 4) PAGE 6－4
Chapter 6: System Operation
6.1.2 RS-232C Output Data
Result data is output every time the operation is finished.
The result output is possible for each unit that has a SAN3 –DP2S installed.
Result Output Data
Data Length: 78 bytes fixed (78 letters)
COUNT Number: ‘0001’ is displayed after powering ON. 1 is added after each cycle.
Normal data format (Judgment is an ACCEPT)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
Cycle Count
Press
Number
Parameter
Number
30H 30H 30H 30H 30H 30H 30H 31H 20H 30H 31H 20H 20H 31H 20H 20H
０ ０ ０ ０ ０ ０ ０ １ ０ １ １
17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32
Judgment Load
Judg
ment
Judgment Distance
Judg
ment
31H 32H 2EH 33H 34H 20H 20H 31H 32H 33H 2EH 34H 35H 36H 20H 20H
１ ２ ． ３ ４ １ ２ ３ ． ４ ５ ６
33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48
Final Load
Judg
ment
Final Distance
Judg
ment
31H 32H 2EH 33H 34H 20H 20H 31H 32H 33H 2EH 34H 35H 36H 20H 20H
１ ２ ． ３ ４ １ ２ ３ ． ４ ５ ６
49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64
Part Check 1 Distance
Judg
ment
Part Check 2 Maximum Load
Judg
ment
31H 32H 33H 2EH 34H 35H 36H 20H 20H 31H 32H 2EH 33H 34H 20H 20H
１ ２ ３ ． ４ ５ ６ １ ２ ． ３ ４
65 66 67 68 69 70 71 72 73 74 75 76 77 78
Part Check 3 Maximum Load
Judg
ment
Judg
ment
Rea
son
ＣＲ ＬＦ
31H 32H 2EH 33H 34H 20H 20H 20H 4FH 20H 20H 20H 0DH 0AH
１ ２ ． ３ ４ Ｏ
Overall Judgment
"Ｏ"(4FH)：ＡＣＣＥＰＴ
"00000001 01 1 12.34 123.456 12.34 123.456 123.456 12.34 12.34 O "+CR+LF
Letters Displayed After Judgment Load:
Letters Displayed After Judgment Distance:
" "(20H)：ACCEPT
"Ｈ"(48H)：HIGH REJECT
"Ｌ"(4CH)：LOW REJECT
Letters Displayed After Check 1,2 or 3 Data:
" "(20H)：ACCEPT
"Ｈ"(48H)：HIGH REJECT
"Ｌ"(4CH)：LOW REJECT
"Ｚ"(5AH)：INTERFERENCE CHECK
REJECT
(After CHECK 1 Data)
Overall Judgment Letters:
"Ｏ"(4FH)：ACCEPT
"Ｘ"(58H)：REJECT
Reason Letter (Stop Reason):
" "(20H)：Normal
"Ａ"(41H)：Abnormal
"Ｓ"(53H)：STOP(Loss of Stop Signal)
"Ｂ"(42H)：BYPASS
"Ｒ"(52H)：STOP CCW
"Ｆ"(46H)：STOP CW
"Ｅ"(45H)：STARTOFF
