enFORCE DSP1500 SAN Unit Operation Manual
(Rev 4) PAGE 6－20
Chapter 6: System Operation
¾ Data Number 20 Tool Number
The connected tool number is set from the following tool table.
Tool
Number
Tool Name
（ F-Type）
Maximum
Load
[KN]
Maximum
Speed
[mm/sec]
Minimum
Speed
[mm/sec]
Load
Decimal
Point
Speed
Decimal
Point
30 DPT-021R1-**F 1.96 416.6 0.4 XX.XX XXX.X
31 DPT-051R2A-**F 4.90 333.3 0.3 XX.XX XXX.X
32 DPT-101R3-**F 9.81 277.7 0.3 XX.XX XXX.X
33 DPT-151R3-**F 14.7 277.7 0.3 XXX.X XXX.X
43 DPT-201R3-**F 19.6 166.6 0.2 XXX.X XXX.X
42 DPT-301R4H-**F 29.4 320.0 0.7 XXX.X XXX.X
40 DPT-501R4H-**F 49.0 200.0 0.5 XXX.X XXX.X
41 DPT-701R4H-**F 68.6 133.3 0.3 XXX.X XXX.X
37 DPT-102R5-**F 98.1 116.6 0.4 XXX.X XXX.X
38 DPT-152R5-**F 147.1 77.77 0.22 XXX.X XX.XX
39 DPT-202R5-**F 196.1 58.33 0.16 XXX.X XX.XX
80 DPT-501R5C-**F 49.0 222.2 0.6 XXX.X XXX.X
81 DPT-202R5A-**F 196.1 66.67 0.17 XXX.X XX.XX
Tool
Number
Tool Part No.
(P-Type)
Maximum
Load
[KN]
Maximum
Speed
[mm/sec]
Minimum
Speed
[mm/sec] Load
Decimal
Point
Speed
Decimal
Point
50 DPT-021R3-**P 1.96 208.3 0.2 XX.XX XXX.X
51 DPT-051R3-**P 4.90 95.24 0.01 XX.XX XX.XX
52 DPT-101R4H-**P 9.81 133.3 0.3 XX.XX XXX.X
62 DPT-151R4H-**P 14.71 114.2 0.3 XX.XX XXX.X
54 DPT-201R4H-**P 19.61 80.00 0.16 XX.XX XX.XX
55 DPT-301R4H-**P 29.42 64.00 0.14 XX.XX XX.XX
56 DPT-501R5-**P 49.03 66.66 0.17 XX.XX XX.XX
57 DPT-102R5-**P 98.10 33.33 0.09 XXX.X XX.XX
58 DPT-152R5B-**P 147.1 22.22 0.06 XXX.X XX.XX
59 DPT-202R5B-**P 196.1 16.37 0.05 XXX.X XX.XX
64 DPT-501R5B-**P 49.03 58.33 0.17 XX.XX XX.XX
63 DPT-102R5B-**P 98.1 29.16 0.09 XXX.X XX.XX
65 DPT-051R3-**P 4.90 95.24 0.01 XX.XX XX.XX
Tool
Number
Tool Part No.
“Mini”
Maximum
Load
[KN]
Maximum
Speed
[mm/sec]
Minimum
Speed
[mm/sec] Load
Decimal
Point
Speed
Decimal
Point
113 DPM-050H1-**P 0.500 133.3 0.4 X.XXX XXX.X
114 DPM-100H1-**F 1.000 180.0 0.4 X.XXX XXX.X
Tool
Number
Tool Part No.
“Slimline”
Maximum
Load
[KN]
Maximum
Speed
[mm/sec]
Minimum
Speed
[mm/sec] Load
Decimal
Point
Speed
Decimal
Point
85 DPS-101R3-**F 10.0 222.2 0.3 XXX.X XXX.X
84 DPS-301R4H-**F 30.0 200.0 0.5 XXX.X XXX.X
89 DPS-501R4H-**F 50.0 160.0 0.4 XXX.X XXX.X
88 DPS-501R5-**F 50.0 200.0 0.5 XXX.X XXX.X
*The most common models are shown. Contact FEC for models not shown above.
