FEC DSP1500 (SAN3) User Manual
Page 97
enFORCE
DSP1500 SAN Unit Operation Manual
PAGE 6－21 (Rev
4)
Chapter 6: System Operation
¾
Data Number
30
Home Position Search Time Out [0 ~ 999.9 sec.]
It sets the time limit of the home position search operation. The default setting is 120.0.
*If the operation has not finished within the time limit an abnormal will occur and the
Reject light will flash.
¾
Data number
31
Home Position Search Speed [Tool minimum speed ~ 10mm/sec.]
This data field sets the speed of the Home Position Search operation.
* The maximum speed of the Home Position Search operation is 10mm/sec. If the value
set is higher than 10mm/sec., the speed will be limited to 10mm/sec.
¾
Data Number
32
Manual Operation Speed [Tool minimum speed ~ maximum speed]
This data field sets the speed of MANUAL operations. The manual Jog operating speed
and the speed of the Home Return operation will be set to this value.
¾
Data Number
33
Stroke Distance Limit [0 ~ 999]
This data field sets the maximum stroke the press will be allowed. If set to zero, the
distance is unlimited. The default setting is zero.
* If setting Distance High Limit Stop [00-37] to “1” a Stroke Distance Limit must be set. If
set to zero Distance High Limit Stop will be disabled.
¾
Data Number
34
Approach Distance Limit [0 ~ 999]
This data field sets the distance limit that the press can run at Approach Speed. If set to
zero, the distance is unlimited. The default setting is zero.
¾
Data Number
35
Home Returned Signal Output Range [0 ~ 999]
The Home Returned signal will be output when the press stops within +1mm of the value
set.
(Ex: If 10 is set, the Home Returned signal will be output if the press stops between 0
and 11mm)
The default setting is zero.
¾
Data number
36
Load Cell / Dynamic Hold / Home Sensor / RS232&485 Comm. Speed
□ □ □ □
0: Load Cell [Yes] (Default)
1: Load Cell [No]
0: Dynamic Hold [On] (Default)
1: Dynamic Hold [Off]
Dynamic Hold should be set to 0 [ON] unless
instructed by FEC. This allows the servo motor to
hold the press ram when the operation has stopped.
If Dynamic Hold option is set to 1 [OFF], system will
automatically be set to SERVO OFF mode after the
operation has finished.
0: Home Position Sensor [No] (Default)
1: Home Position Sensor [Yes] (Option on larger presses)
*0: RS-485
9600bps RS-232C
9600bps
*1:
19200bps 9600bps
2: 38400bps 9600bps
*3: 9600bps 19200bps
*4:
19200bps 19200bps
5:
38400bps 19200bps
*6:
9600bps 38400bps
*7:
19200bps 38400bps
8:
38400bps 38400bps
Power must be cycled for these changes to take effect.
*Available only when configured for Stand Alone
