enFORCE DSP1500 SAN Unit Operation Manual
(Rev. 4) PAGE 4－20
Chapter 4: System Setup and Wiring
ƒ CK2_HIGH: [OUT DATA7] Part Check 2 High REJECT Signal
Output when the load sensed by the press between Part Check 2 Start Distance and
Part Check 2 End Distance is above the acceptable Part Check 2 Load High Limit.
Output remains active until the start or reset signal is input.
ƒ CK3_LOW: [OUT DATA8] Part Check 3 Low REJECT Signal
Output when the load sensed by the press between Part Check 3 Start Distance and
Part Check 3 End Distance is below the acceptable Part Check 3 Load Low Limit.
Output remains active until the start or reset signal is input.
ƒ CK3_HIGH: [OUT DATA9] Part Check 3 High REJECT Signal
Output when the load sensed by the press between Part Check 3 Start Distance and
Part Check 3 End Distance is above the acceptable Part Check 3 Load High Limit.
Output remains active until the start or reset signal is input.
ƒ BANK 1: [OUT DATA10] Bank 1 Input Echo Signal
Output when the BANK SELECT 1 input is high (On).
ƒ BANK 0: [OUT DATA11] Bank 0 Input Echo Signal
Output when the BANK SELECT 0 input is high (On).
ƒ ABNSUB_CODE0: [OUT DATA0] Abnormal Sub Code Bit 0 Signal
Bits 0 thru 3 are binary bits used together to represent the Abnormal Sub Code.
Output remains active until the reset signal is input.
ƒ ABNSUB_CODE1: [OUT DATA1] Abnormal Sub Code Bit 1 Signal
Bits 0 thru 3 are binary bits used together to represent the Abnormal Sub Code.
Output remains active until the reset signal is input.
ƒ ABNSUB_CODE2: [OUT DATA2] Abnormal Sub Code Bit 2 Signal
Bits 0 thru 3 are binary bits used together to represent the Abnormal Sub Code.
Output remains active until the reset signal is input.
ƒ ABNSUB_CODE3: [OUT DATA3] Abnormal Sub Code Bit 3 Signal
Bits 0 thru 3 are binary bits used together to represent the Abnormal Sub Code.
Output remains active until the reset signal is input.
ƒ ABN_CODE0: [OUT DATA4] Abnormal Code Bit 0 Signal
Bits 0 thru 3 are binary bits used together to represent the Abnormal Code.
Output remains active until the reset signal is input.
ƒ ABN_CODE1: [OUT DATA5] Abnormal Code Bit 1 Signal
Bits 0 thru 3 are binary bits used together to represent the Abnormal Code.
Output remains active until the reset signal is input.
ƒ ABN_CODE2: [OUT DATA6] Abnormal Code Bit 2 Signal
Bits 0 thru 3 are binary bits used together to represent the Abnormal Code.
Output remains active until the reset signal is input.
ƒ ABN_CODE3: [OUT DATA7] Abnormal Code Bit 3 Signal
Bits 0 thru 3 are binary bits used together to represent the Abnormal Code.
Output remains active until the reset signal is input.
ƒ BANK 1: [OUT DATA10] Bank 1 Input Echo Signal
Output when the BANK SELECT 1 input is high (On).
ƒ BANK 0: [OUT DATA11] Bank 0 Input Echo Signal
Output when the BANK SELECT 0 input is high (On).
OUTPUT BANK 4: Bank0 – On / Bank1 - On
