Chapter 3: System Description
3.3 Press Tool
Drawing Shown For Reference Only
A)
MOTOR:
Totally
enclosed
DC
permanent
magnet
motor
Refer
to
Chapter
2
for
available
motor
sizes
B) RESOLVER:
Provides feedback for speed regulation to servo amplifier
Provides
distance
monitoring
capability
to
press
operation
C)
PRE-AMPLIFIER:
Amplifies load transducer signal.
Houses
“I.D.
chip”
used
to
verify
tool
functionality
D) LOAD CELL:
Precision strain gage load transducer
Provides
press
force
feedback
to
servo
amplifier
E) HOME POSITION PROXIMITY:
Counter-clockwise (return) limit sensor
(Not
present
on
DPM
Series)
F) ADVANCED PROXIMITY:
Clockwise (advance) limit sensor
(Not
present
on
DPS
or
DPM
Series)
G) GEAR HOUSING:
Durable gear transmission. (Belt Drive on DPS & DPM)
H)
SPLINE:
Ball
screw
driven
press
ram
I) MOUNTING FLANGE:
See Chapter 2 for size and hole pattern
J) GREASE FITTING:
Spline lubrication point.
K)
LUBE ACCESS POINT:
Gear lubrication point (availability and location dependant
on
press
size
and
series)
