enFORCE DSP1500 SAN Unit Operation Manual
PAGE 2－7 (Rev. 4)
Chapter 2: Specifications
2.3.2 Tool Specifications
Motor: Permanent magnet DC
Force Monitor: Inline Load Cell
Distance Monitor: High Resolution Resolver
List of standard tools for press-fitting (F type) - Use when operating with instantaneous load.
Tool No. Tool type
Maximum load
[KN]
Maximum speed
[mm/sec]
Minimum speed
[mm/sec]
114 DPM-011H1-**F 1.000 130.0 0.4
30 DPT-021R1-**F 1.96 416.6 0.4
31 DPT-051R2-**F 4.90 333.3 0.3
32 DPT-101R3-**F 9.81 277.7 0.3
85 DPS-101R3-**F 10.0 222.2 0.3
33 DPT-151R3-**F 14.7 277.7 0.3
13 DPT-151R4H-**F 14.7 296.3 0.6
43 DPT-201R3-**F 19.6 166.6 0.2
09 DPT-201R4H-**F 19.6 200.0 0.5
42 DPT-301R4H-**F 29.4 320.0 0.7
84 DPS-301R4H-**F 30.0 200.0 0.7
40 DPT-501R4H-**F 49.0 200.0 0.5
89 DPS-501R4H-**F 50.0 160.0 0.4
14 DPT-501R5-**F 49.0 194.4 0.6
41 DPT-701R4H-**F 68.6 133.3 0.3
37 DPT-102R5-**F 98.1 116.6 0.4
38 DPT-152R5-**F 147.1 77.77 0.22
81 DPT-202R5A-**F 196.1 66.67 0.17
List of standard tools for press-bonding (P type) - Use when operating while holding load.
Tool No. Tool type
Maximum load
[KN]
Maximum speed
[mm/sec]
Minimum speed
[mm/sec]
113 DPM-050H1-**P 0.500 130.0 0.4
50 DPT-021R3-**P 1.96 208.3 0.2
65 DPT-051R3-**P 4.90 95.24 0.01
52 DPT-101R4H-**P 9.81 133.3 0.3
62 DPT-151R4H-**P 14.71 114.2 0.3
54 DPT-201R4H-**P 19.61 80.00 0.16
55 DPT-301R4H-**P 29.42 64.00 0.14
64 DPT-501R5-**P 49.03 58.33 0.17
68 DPT-701R5-**P 68.65 47.61 0.12
63 DPT-102R5-**P 98.1 29.16 0.09
58 DPT-152R5-**P 147.1 22.22 0.06
59 DPT-202R5-**P 196.1 16.37 0.05
*Standard part numbers shown. Contact FEC for non-standard part specifications.
1KN = 224.81 Lbs.
