enFORCE DSP1500 SAN Unit Operation Manual
(Rev. 4) PAGE 4－12
Chapter 4: System Setup and Wiring
*Allow at least 20ms from the time the desired bank is selected before reading the OUT DATA
signal.
BANK1 BANK0 OUT DATA Signal Name Description
OFF OFF
OUT DATA0 SERVO ON Output when press motor is on (running)
OUT DATA1 HOME SET Output after home position has been defined.
OUT DATA2 PRESS RET’D Output when the press is stopped in home position.
OUT DATA3 BUSY Output while operating.
OUT DATA4 READY Output when the system is READY to operate.
OUT DATA5 ABNORMAL Output when an Abnormal condition occurs.
OUT DATA6 ACCEPT Output when the system has halted without failure.
OUT DATA7 REJECT Output when the system has halted with failure.
OUT DATA8 ADVANCED Output when the press has reached target load or distance.
OUT DATA9 ADV / RET POS. Advance / Return Position Output signal.
OUT DATA10 BANK1 Output echo of BANK Select 1 Input.
OUT DATA11 BANK0 Output echo of BANK Select 0 Input.
OFF ON
OUT DATA0 HOME RET’D
Output when the press is between Home Position and the
position shown in System Parameter 00-35.
OUT DATA1 BYPASS Output when the press is in Bypass (switch or input)
OUT DATA2
OUT DATA3 WORK SELECT 4
Output echo of selected Input.
OUT DATA4 WORK SELECT 3
OUT DATA5 WORK SELECT 2
OUT DATA6 WORK SELECT 1
OUT DATA7 WORK SELECT 0
OUT DATA8
OUT DATA9
OUT DATA10 BANK1 Output echo of BANK Select 1 Input.
OUT DATA11 BANK0 Output echo of BANK Select 0 Input.
ON OFF
OUT DATA0 LOAD_LOW Output on a Low Load Reject.
OUT DATA1 LOAD_HIGH Output on a High Load Reject.
OUT DATA2 DIS_ LOW Output on a Low Distance Reject
OUT DATA3 DIS_ HIGH Output on a High Distance Reject
OUT DATA4 CK1_LOW Output on a Check 1 Low Reject
Hi h Ab l
Both ON:
Interference Reject
OUT DATA5 CK1_HIGH Output on a Check 1 High Reject
OUT DATA6 CK2_LOW Output on a Check 2 Low Reject
OUT DATA7 CK2_HIGH Output on a Check 2 High Reject.
OUT DATA8 CK3_LOW Output on a Check 3 Low Reject
OUT DATA9 CK3_HIGH Output on a Check 3 High Reject.
OUT DATA10 BANK1 Output echo of Bank Select 1 Input.
OUT DATA11 BANK0 Output echo of Bank Select 0 Input.
ON ON
OUT DATA0 ABNSUB-CODE0 Abnormal Sub Code Bit 0 Output
OUT DATA1 ABNSUB-CODE1 Abnormal Sub Code Bit 1 Output
OUT DATA2 ABNSUB-CODE2 Abnormal Sub Code Bit 2 Output
OUT DATA3 ABNSUB-CODE3 Abnormal Sub Code Bit 3 Output
OUT DATA4 ABN-CODE0 Abnormal Code Bit 0 Output
OUT DATA5 ABN-CODE1 Abnormal Code Bit 1 Output
OUT DATA6 ABN-CODE2 Abnormal Code Bit 2 Output
OUT DATA7 ABN-CODE3 Abnormal Code Bit 3 Output
OUT DATA8
OUT DATA9
OUT DATA10 BANK1 Output echo of Bank Select 1 Input
OUT DATA11 BANK0 Output echo of Bank Select 0 Input.
