enFORCE
DSP1500 SAN Unit Operation Manual
PAGE 4-11 (Rev.
4)
Chapter 4: System Setup and Wiring
4.7.2 PLC Interface (I/O) Signals [Stand Alone Configuration]
IN: Input Signal OUT: Output Signal NC: Normally Closed NO: Normally Open
4.7.2.1 Output Data Bank Signals (Stand Alone Configuration Only)
Bank Select Inputs are used to “multiplex” the output signals allowing up to 32 signals from only 8
physical outputs. By changing the input conditions of these two inputs, up to four “Banks” may be
selected changing the definition of each output point.
The SERVO ON signal is sometimes monitored to operate the brake. When changing
Banks, the meaning of the SERVO ON signal will change when a bank other than Bank
1 is selected. (See Section 4.14 for Brake Operation)
Pin No.
Signal Name
IN/OUT
Description
1
STOP
IN (N.C.) Stops System operation upon loss of signal.
2
RESET
IN (N.O.) Resets to the initial condition. (>100 ms pulse)
3 MANUAL
IN
(N.O.)
Manual
mode.
4
START
IN (N.O.) Starts Press Cycle.
5
BYPASS
IN (N.O.) Disables Press operation.
6 NOT
USED
No
Connection
Allowed
7 NOT
USED
No
Connection
Allowed
8 NOT
USED
No
Connection
Allowed
9
HOME / OPTION IN
IN (N.O.) Home sensor input/Option In input (Use for special applications)
10
BANK 1
IN (N.O.) Bank 1 Select input
11
BANK 0
IN (N.O.) Bank 0 Select input
12 NOT
USED
No
Connection
Allowed
13
IN COMMON
Input signal common. (+12 ~ +24VDC)
14
SELF CHECK OFF
IN (N.O.) Disable the self-check function.
15
CW LIMIT
IN (N.C.) CW limit sensor input.(Advance limit)
16
CCW LIMIT
IN (N.C.) CCW limit sensor input.(Return limit)
17
WORK SELECT 0
IN (N.O.) These 5 inputs form a binary code which is capable of selecting up to
32 different parameters.
(In Manual Mode these inputs become selecting signals for advance,
return, home-position search and home-position return operations.)
18 WORK
SELECT
1
IN
(N.O.)
19 WORK
SELECT
2
IN
(N.O.)
20 WORK
SELECT
3
IN
(N.O.)
21 WORK
SELECT
4
IN
(N.O.)
22 OUT
DATA11
OUT (N.O.) Echo of Bank 0 Select Signal
23
OUT COMMON
Output signal common. (0VDV)
24 OUT
DATA0
OUT (N.O.)
Outputs system condition signals based on which Bank is selected.
Echo of Bank 1 Select Signal
25 OUT
DATA1
OUT (N.O.)
26 OUT
DATA2
OUT (N.O.)
27 OUT
DATA3
OUT (N.O.)
28 OUT
DATA4
OUT (N.O.)
29 OUT
DATA5
OUT (N.O.)
30 OUT
DATA6
OUT (N.O.)
31 OUT
DATA7
OUT (N.O.)
32 OUT
DATA8
OUT (N.O.)
33 OUT
DATA9
OUT (N.O.)
34 OUT
DATA10
OUT (N.O.)
