enFORCE
DSP1500 SAN Unit Operation Manual
PAGE 2－3 (Rev.
4)
Chapter 2: Specifications
2.2 SAN Unit Specifications
CPU:
32 bit RISC (Reduced Instruction Set CPU)
Data Communication:
RS485 (2 Ports) – 1 for DSP User Console Software
Parameter / Firmware Storage:
Flash ROM
SAN Unit Type
SAN3 - 24HS
SAN4 - 24HS
SAN3 - 24S
SAN4 - 24S
SAN3 - 40S
SAN4 - 40S
SAN3 - 120S
SAN4 - 120S
Motor Type
RH1 RM1 RM2 RM3 RM4 RM5
SAN3 Unit
Input Power
180 ~ 242VAC, 3φ
SAN4 Unit
Motor Power
SAN Unit
Frequency
50 / 60Hz
Max. Power
Output
70W 60W
80W
200W
1500W
3000W
In-rush
Current
19A 9.5A
18A
38.6A
7 9 . 2 A
116.4A
SAN Power
Consumption
18W IDLE
25W*
IN CYCLE
23W*
IN CYCLE
55W*
IN CYCLE
88W* IN
CYCLE
1 0 7 W *
IN CYCLE
1 3 4 W *
IN CYCLE
* Total watts calculated running at 97% capacity, 99% stroke and 60% duty cycle.
SAN4 Control Power Supply Circuit
Input Power Source Voltage
(Power Source Frequency)
Single phase 180V – 242V AC (50/60HZ)
Momentary Maximum Current
(Including Inrush Current)
0.25A rms (36Amax)
After powering down wait at least 5 seconds (1 minute recommended) before
powering up again. If the equipment is powered “ON” and “OFF” repeatedly without
this delay, the in-rush current circuit will stop the unit from functioning. If this
happens it may take up to five minutes before the unit will power up again.
2.2.1 Duty Cycle Calculation
Duty Cycle is rated as a percentage of the time the motor is running to the overall cycle time of
the machine. This is an important factor in determining overload protection for servo amplifiers
and motors as it directly relates to the amount of power or heat dissipation of the motor / servo
package. The rated duty cycle for the
enFORCE
system is calculated as follows:
Duty Cycle Percentage (％) =
Tool Pressing Time x 100
Total Cycle Time (Tool Pressing + Tool Waiting)
Duty cycle ratings vary between tools. As a general rule, however, it should not exceed 60%. If
duty cycles remain above 60% for extended periods, a “Servo Amplifier Error / Overload” will
result (see Abnormal Code 8-10). Protection for high duty cycle is a standard feature of the
servo amplifier to prevent servo or motor damage.
