FEC DSP1500 (SAN3) User Manual
Page 26
enFORCE
DSP1500 SAN Unit Operation Manual
(Rev. 4)
PAGE 2－6
Chapter 2: Specifications
2.3 Press Tool
2.3.1 Part Number Breakdown
[DPT]-[151]R[3][ ]-[25][F][S][B]-[00][A]
A B C D E F G H I J
(A) PRESS SERIES
( )DPT = STANDARD
(*)DPM = MINI SERIES (500 & 1000N)
(**)DPS = SLIM-LINE SERIES (1, 3 & 5ton)
(B) PRESS FORCE
050=0.05ton *
201=2.0ton
202=20.0ton
(In Metric Tons)
011=0.1ton *
301=3.0ton **
021=0.2ton
501=5.0ton
**
051=0.5ton
701=7.0ton
101=1.0ton
**
102=10.0ton
151=1.5ton
152=15.0ton
(C)
MOTOR
1
=
RM1A
H1 = RM1H
2A = RM2A
3 = RM3A
4 = RM4
4H = RM4H
5 = RM5
(D)
REVISION
BLANK
=
STANDARD
MOTOR
A,
3,
ETC.
=
ALPHA
NUMERIC
REVISION
CODE
(E)
STROKE
10
=
100mm
15
=
150mm
etc…..
25
=
250mm
20
=
200mm
(F) PRESS TYPE
F = PRESSING (Holding time <1sec.) - DPT & DPS
P
=
BONDING
(Holding
time
>1sec.)
-
DPT
&
DPM
(G) SHAFT TYPE (DPT)
S = SPLINE SHAFT
G = GUIDE SHAFT
(H) MAINTENANCE LOCK
B = WITH LOCK
BLANK = NO LOCK
(I)
MOUNTING
00
=
STANDARD
(BACK
MOUNTING)
01
=
90
DEGREES
02
=
TAPPED
03 = FRONT MOUNTING
10
=
SPECIAL
(CUSTOM
DESIGN)
(J) VERSION/REVISION
A = CURRENT
B = FUTURE UPGRADES
C
=
FUTURE
UPGRADES
