MOD30ML and Modcell Maintenance Manual
COMMUNICATIONS
Message Probable Cause Action
Memory module (or LCP
backup database) not present A memory module has not been
installed in the instrument. Install memory module.
Module database invalid
1. Information about memory
module.
2. Communications port
mismatch detected during
download of backup main
database from memory
module.
3. No valid database in module.
4. Module database checksum
error.
5. Module database version
error.
1. Read diagnostics to determine
specific cause.
2. Verify that database contains
an ICN block or MSC block
which matches the instrument
communications module.
Matching includes slot
numbers, module type, and
module address switch setting
unless ANY is configured.
3. Load a valid module database.
4. Same as above.
5. Same as above.
Module switch in upload
The memory module
NORMAL/MODULE LOAD switch
is set at MODULE LOAD.
Change switch setting if required.
Module write protected Memory
module READ/WRITEREAD
ONLY switch is set at READ
ONLY to protect backup database
from being overwritten. If overwriting is required, change
switch setting to READ/WRITE
Module write protected Memory module READ/
WRITEREAD ONLY switch is set
at READ ONLY to protect backup
database from being overwritten. If overwriting is required, change
switch setting to READ/WRITE
No response was received
1. Specified ICN or Modbus
address is not correct.
2. Instrument is not connected
to network.
1. Enter correct address on
Communications Setup menu
(See Section 3.2.2).
2. Check network connections.
Not a MODCELL database
1. Unable to decompile
instrument database (.ID1)
file during upload from
instrument to Application
builder.
2. Unable to decompile 1706S
Configurator .ID1 file during
import into Application
Builder.
1. Try upload operation again.
2. Be sure the .ID1 file contains a
valid instrument database,
then try import operation
again.
Not authorized source Another source is in control of the
loop.
Wait for the other source to
release control, or issue an
override control message.
Not enough fields for a multiple
field entry
Insufficient data was specified in
a command.
e.g., W EX1,I3 1.2
(data type not specified;
W EX1,I3 1.2 F is correct) Correct entry and try again.
