MOD30ML and Modcell Maintenance

VIEWING DIAGNOSTIC DATA

3 Press down arrow to enter the event queue. Page 1 for the first event in the queue

appears (figure at the bottom left of next page).

4. View the events in the queue as follows:

• Press the down arrow again to view page 2 for the first event.
• Press the up arrow to return to page 1.
• Press NXT to view the next event; use down and up to view page 2 as required.
• Use the block type and event code, to locate the event description and

recommended action listed in Section 7.3.

5. Continue using the NXT, Down, Up sequence to view all the event data in the queue.

6. Press the TAG key to return to the DEVICE/EVENTS display, then press again to return to

the runtime display.

3 -30
