MOD30ML and Modcell Maintenance Manual
EVENT CODES AND TRANSITION MESSAGES

Table 7-2. Event Codes, Description and Action (Cont’d)

Block

Type

Codes

Full Message Text

Description/Action

RIO

4

I/O MISMATCH

A configured slot is either empty or the installed
module does not match the slot configuration.

RIO

5

CS-31 BUS COMMUNICATION ERROR

There is an error in communication or loss of
communication between the RIO interface
module and the CS-31 bus.

RIO

6

I/O COMMUNICATIONS ERROR

An error occurred in communication between
the RIO module and the instrument.

RIO

7

CS-31 DATABASE CHECKSUM ERROR

The remote I/O database stored in the interface
module has been declared bad due to a
checksum error.

RIO

8

MODULE EXTENDED ERROR

There is an RIO module error.

RTI

0

BLOCK STATE SET TO RUN

Information only.

RTI

1

BLOCK STATE SET TO HOLD

Information only.

RTI

2

BLOCK STATE SET TO OFF

Information only.

RTI

3

BLOCK STATE SET TO DEBUG

Information only.

RTI

4

CALCULATION ERROR

A calculation error (calculation overflow or
divide by zero) has been detected. The block
completes the calculation using some
reasonable value (+ or - maximum value for
overflows and divide by zero), and sets the
output quality bad if Attribute No. 10, Set quality
bad on calculation error? (SETQBAD) is YES.
The diagnostic error clears and the quality is
set back to good when a subsequent execution
of the block performs a successful calculation.

RTTI

0

BLOCK STATE SET TO RUN

Information only.

RTTI

1

BLOCK STATE SET TO HOLD

Information only.

RTTI

2

BLOCK STATE SET TO OFF

Information only.

RTTI

3

BLOCK STATE SET TO DEBUG

Information only.

RTTI

4

CALCULATION ERROR

A calculation error (calculation overflow or
divide by zero) has been detected. The block
completes the calculation using some
reasonable value (+ or - maximum value for
overflows and divide by zero), and sets the
output quality bad if Attribute No. 10, Set quality
bad on calculation error? (SETQBAD) is YES.
The diagnostic error clears and the quality is
set back to good when a subsequent execution
of the block performs a successful calculation.

7 -16
