Technical notice, Reference – Micromod MOD: 30ML and Modcell Maintenance for 2001N, 2002N, and 1800R User Manual
Page 144
Technical Notice
I/O Grounding
• The built-in analog outputs are internally tied to circuit common, and require no external grounding.
• The built-in analog inputs, and all modular analog I/O, are isolated and should be externally
grounded.
Reference:
TechNote
TNML0801-2
Faceplate Communication Errors
Instruction
IB-MODBUS-RTU
Modbus RTU Communications Guide
Instruction
IB-1800R-INS
MOD30ML Installation Guide
Instruction
IB-23C601
Remote I/O Module Installation Guide
Support Web Site
Topic: MOD 30ML/Modcell
Technote: TNML1001-1
MicroMod Automation, Inc.
Rev. 3, Feb-2005
GroundingWiring.doc
Page 4 of 4
