Communication Cables Pin-Outs

Cables for Minilink, Comm link and MOD 30ML


Problem Description:

This tech-note covers the pin-outs for the communication cables used with the MOD 30, MOD 30ML and

Modcell equipment.

Applies to:

MOD 30, MOD 30ML, Modcell, Comm link (1720N), Mini-link Ext (1733N) and personal computer.

Explanation:

Following is a table that summarizes the cables:

Cable Model Number

Connecting eqipment

Communication Satndard

109S1854

MOD 30ML Built-in RS-232 port in the

front on the controller to PC

RS-232

1774F

Comm link (1720N) and PC’s 9 pin serial

port

RS-232

1753F

Comm link (1720N) and PC’s 25 pin serial

port

RS-232

Generic

Mini link – Ext (1733N) 9 pin port and

PC’s 9 pin serial port

RS-232

Generic

Mini link – Ext (1733N) 9 pin port and

PC’s 25 pin serial port

RS-232

Generic

Mini link – Ext (1733N) 25 pin port and

PC’s 25 pin serial port

RS-232

Generic

Mini link – Ext (1733N) 25 pin port and

PC’s 9 pin serial port

RS-232

Topic: MOD 30ML/Modcell

Technote: TNML0702-1

MicroMod Automation, Inc.

Rev. July-2002

Comm Cables.doc

Page 1 of 4
