MOD30ML and Modcell Maintenance

VIEWING DIAGNOSTIC DATA

Table 3 .8. Status Window Commands

Command

Description

Equivalent

Command

ACK_SD

Acknowledge shutdown fault

W IF1,CMD 1

UP_MOD

Upload to module

W IF1,CMD 2

DOWN_MOD

Download from module

W IF1,CMD 3

SET_WP

Set module write protect

W IF1,CMD 4

CLR_WP

Clear module write protect

W IF1,CMD 5

DEL_MAIN

Delete main data base

W IF1,CMD 6

RES_MAIN

Restore main data base

W IF1,CMD 7

RESET

Restart instrument after task completes

W IF1,CMD 8

KILL

Restart instrument before completing task

W IF1,CMD 9

CLR_MT

Clear maximum execution times

W IF1,CMD 10

CLR_Q

Clear system event queue

W SE1,CLRQCMD 1

ACK_ALL

Acknowledge all diagnostics, notification/
request messages, and process alarms

W SE1,GLBACK 1

ACK_DIAGS

Acknowledge all diagnostics

W SE1,DGACK 1

ACK_ALMS

Acknowledge all process alarms

W SE1,PAACK 1

R TIME

R DATE
R DAY

Read instrument time of day (Time includes
Date and Day or they can issued separately)
Read instrument calendar date
Read instrument day of week

R IF1,TIMEDAY

R IF1,DATE
R IF1,DAY

R IOLOCK

Read instrument I/O Lock status

R IF1,IOLOCK

R STATE

Read instrument state

R IF1,INSTATE

W TIME

data

Write instrument time of day

W IF1,TIMEDAY

data

W DATE

data

Write instrument calendar date

W IF1,DATE

data

W DAY

data

Write instrument day of week

W IF1,DAY

data

W STATE

data

Write instrument state

W IF1,NXTISTAT

data

R FG

Read Minimum Foreground

None

R FGO

lsp

Read Foreground offset of attribute

None

R BLOCK

blkocc#

Read block and display bytes in hex

None

R VERSION

1

Read instrument version

None

R SD

type

2

Read instrument shutdown area type

None

R

lsp

Read specified attribute

None

R

lsp type

3

Read Byte Before attribute

None

RS

lsp

Read specified string attribute

(RS IF1,USRTAG)

None

RS

lsp type

3

Read Byte Before string attribute

(RS EX1,13 H)

None

W

lsp data

Write specified attribute

None

W

lsp data type

3

Write Byte Before attribute

None

ACK

blkocc# diag#

4

acknowledge diagnostic point (e.g. ACK IF1
9)

None

NOTES for Table 3.8:

1. R VERSION command applies to any instrument on the network (ICN or Modbus) and is

returned as follows (current versions are bold, MOD 30 instruments start with C, R, A, or S
version id return data):
Description

Return

Data

2001P MODCELL Logic Controller Version 6

BxA__6xxxxxxx

(Version 1, 2, 3, 4, 5 follow in same fashion)

BxA__...

2002P MODCELL Regulatory Controller Version 3 DxA__3xxxxxxx
(Version 1, 2 follow in same fashion)

DxA__...

3 -27
