MOD30ML and Modcell Maintenance Manual

EVENT CODES AND TRANSITION MESSAGES

Table 7-2. Event Codes, Description and Action (Cont’d)

Block

Type

Codes

Full Message Text

Description/Action

SE

4

ALL DIAG, PA AND NM GLOBALLY
ACKED.

Information only.

SE

5

ALL DIAGNOSTICS GLOBALLY ACKED. Information only.

SE

6

ALL PROCESS ALARMS GLOBALLY
ACKED.

Information only.

SE

7

ALL NOTIF/REQ MSGS GLOBALLY
ACKED.

Information only.

SE

8

ALL GROUP DIAGNOSTICS
SUPPRESSED

Information only.

SE

9

ALL GROUP DIAGNOSTICS ENABLED

Information only.

SE

10

GROUP 1 DIAGNOSTICS SUPPRESSED Information

only.

SE

11

GROUP 1 DIAGNOSTICS ENABLED

Information only.

SE

12

GROUP 2 DIAGNOSTICS SUPPRESSED Information

only.

SE

13

GROUP 2 DIAGNOSTICS ENABLED

Information only.

SE

14

GROUP 3 DIAGNOSTICS SUPPRESSED Information

only.

SE

15

GROUP 3 DIAGNOSTICS ENABLED

Information only.

SE

16

GROUP 4 DIAGNOSTICS SUPPRESSED Information

only.

SE

17

GROUP 4 DIAGNOSTICS ENABLED

Information only.

SE

18

GROUP 5 DIAGNOSTICS SUPPRESSED Information

only.

SE

19

GROUP 5 DIAGNOSTICS ENABLED

Information only.

SE

20

GROUP 6 DIAGNOSTICS SUPPRESSED Information

only.

SE

21

GROUP 6 DIAGNOSTICS ENABLED

Information only.

SE

22

GROUP 7 DIAGNOSTICS SUPPRESSED Information

only.

SE

23

GROUP 7 DIAGNOSTICS ENABLED

Information only.

SE

24

SYSTEM EVENT QUEUE CLEARED

Information only.

SM

0

BLOCK STATE SET TO RUN

Information only.

SM

1

BLOCK STATE SET TO HOLD

Information only.

SM

2

BLOCK STATE SET TO OFF

Information only.

SM

3

BLOCK STATE SET TO DEBUG

Information only.

SM

4

SUPERVISORY MESSAGE ERROR

A supervisory message failed.

7 -17
