MOD30ML and Modcell Maintenance Manual

PARTS

8.5 PARTS

The following table lists all the saleable parts of the MOD 30ML and Modcell instruments:

Table 8.1 MOD 30ML and Modcell Parts

Part No.

Description

Notes

MOD 30ML

125U2955-3B

Standard display assembly

125U2955-3C

NEMA 4 display assembly

125U2955-3D

Narrow Bezel (1801R) display assembly

125U2955-3E

Russian display assembly

Not published

125U2888-1

CPU board

125U2917-2

Main Board - AC

125U3034-2

Main Board - DC

125U2916-2

Main Board – MOD30 Conversion

DC with MOD30 Cable
Connections

1800FZ00003A

Housing & Termination – Standard

1800FZ00002A

Housing & Termination – MOD30
Conversion

124S2330-4A

Terminal Block – Lower Left (1-15)

124S2330-4B

Terminal Block – Lower Right (Chassis-40)

124S2330-5A

Terminal Block – Upper Left (16-25)

124S2330-5B

Terminal Block – Upper Right (41-Chassis)

MODCELL Multiloop

125U2971-1

Carrier board - Flushmount

125U2874-2

Carrier board - Eurocard

125U2976-1

CPU board - Flushmount

125U2888-1

CPU board - Eurocard

125U2931-1

Select module

Same for Eurocard and Flushmount

125U2873-2

AC Power supply

125U2873-3

AC Power supply - CE Mark

125U2973-1

DC Power supply

There is no CE-mark DC version

175S28

Flushmount termination block kit

Plug-in side of terminations


2050R

125U2951-16

CPU board

125U2955-3

Display assembly

125U2955-3A

2051R display assembly

124S2330-1 Termination

Assembly

Includes Terminal Blocks (3)


The following figures illustrate the MOD 30ML parts for both the standard and the MOD 30
replacement models:





8 -3
