Micromod MOD: 30ML and Modcell Maintenance for 2001N, 2002N, and 1800R User Manual
Page 36
MOD30ML and Modcell Maintenance
VIEWING DIAGNOSTIC DATA
Figure 3.20. Communication Setup
3
Make no changes to the other fields in this dialog
box.
4
Click on OK. This will start the Instrument Status
display as shown below:
This Instrument Status display has a
text field to enter commands and a set
of buttons.
3 -20
