MOD30ML and Modcell Maintenance Manual

COMMUNICATIONS

Table 4 .1. Communication Messages, Cause and Recommended Action

Message

Probable Cause

Action

Attribute not write able

Attribute is read only.

Check the database reference
book for valid read/write data (See
Section 1.5).

Block creation failed

1.

Unable to decompile
instrument database (.ID1)
file during upload from
instrument to Application
Builder.

2.

Unable to decompile 1706S
Configurator .ID1 file during
import into Application
Builder.

1. Try the upload operation

again.



2. Be sure the .ID1 file contains a

valid instrument database and
then try import operation
again.

Cannot change file while OPC
clients are connected to this
server

This message occurs in the OPC
Server if any OPC client is
connected to the server and you
tried to open a different file from
the File menu.

Stop the clients and then try
opening the file again.

Cannot display menu

Insufficient memory.

Provide more memory.

Cannot display status menu

1. Insufficient

memory.

2. KT.MN file has been deleted.

1.

Provide more memory.

2.

Reinstall Application Builder.

Cannot open .ID1 or .ID2 file

1. Instrument data base file

(.ID1) was deleted or not
created.

2.

LCP data base file (.ID2) was
deleted or not created.

1. Repeat compile activity to

create new file, then try to
download again (see IB-
23H141
, Section 5.9).

2.

Repeat data base upload
using LCP Utility, then try to
download again (see IB
23H141
, Section 4.6.6).

Cannot open file SIO. DAT

The Serial I/O Data file containing
communication parameters has
been deleted or the serial port
setup has not been completed.

Perform serial port setup to create
new file (See Section 3.2.1).

Checksum error

1.

Momentary fault in a link
communication.

2.

Incorrect Serial Port Setup.

1. Try

again.

2.

Check Serial Port Setup (see
Section 3.2.1).

CLSIDFormString: Invalid Class
String

This error occurs while entering
one of the following modes:
Status, Upload or Download from
VIZapp Software.

No OPC Server is selected for
communication in the
Communication Setup dialog box.
(See Section 3.3.4 or 3.3.5)

Select an OPC Server for
communication by clicking on the
Browse button on the
Communication Setup dialog box.

4 -12
