SP4000 Flow Computer
12
Explosion Proof Mount (mounting option X)
2.2 Mounting Diagrams:
(continued)
3.25
(82.6)
2.25
(57.2)
2.25
(57.2)
1/2" - 14 NPT Plugs
(2 Places)
1
1.5 (292.1)
6.25 (158.8)
9.125 (231.8)
6.75 (171.5)
10.5 (266.7) 7.75 (196.9)
7.75 (196.9)
Explosion Proof Mount (mounting option E)
9.31
(236.5)
12.06
(306.3)
3.81
(96.8)
6.56
(166.6)
.28 ± .02
(7.1 ± .5)
1.31
(33.3)
8.88
(225.5)
3.5
(88.9)
10.19
(258.8)
2.5
(63.5)
2.5
(63.5)
5.09
(129)
3.0
(76.2)
1/4" - 20UNC-2B
TAP x 5/16" DEEP
(6) HOLES CENTERED
ON THREE SIDES FOR
MOUNTING
1/2"- 14 NPT PLUGS
(2 PLACES)
10.6
(269.2)
1/4" - 20UNC-2B
TAP x 5/16" DEEP
(6) HOLES CENTERED
ON THREE SIDES FOR
MOUNTING
3.5
(88.9)
3
(76.2)
2.13
(54)
1.75
(44.5)
5.1
(129.5)
.25
(6.35) .5
(12.7)
4.63
(117.5)
10.19
(258.8)
3.13
(79.4)
3.13
(79.4)
3
(76.2)
.5
(12.7)
