Screen 2b: Setup LCP File Server (2/2)

Setup LCP File Server

This screen allows the operator to determine whether the

LCP File Server application should boot up with

Caps

Lock On or Off, and whether LCP File Server should boot

up with the system set with

Insert On or Off.

Device displays the current LCP File Server device

number. This is selected from a list box of available

devices with which to communicate. If no

Device numbers

are available, the screen below will display prompting the

operator to enter a

New Device number.

Move the pointer to

Device and press enter. If devices

were configured by the office computer, they will be

displayed in a list box that can contain one or multiple

options. Move the pointer to the desired

Device and

press

ENTER to accept. When the Device is selected,

the

Name field is populated with its name, if provided.

The

Device can refer to any device with which this

DMS i1000 system can communicate. This can be the

office computer, another truck, or some other defined

component.
Name displays the name of current LCP File Server

device. This field is editable. Move the pointer to

Name

and press

ENTER to open a field edit window. Enter the

desired

Name and press ENTER to accept. This name

is now associated with the

Device.

To enter a new

Device, press New (F3) to open a field

edit window and enter a unique value between

1 and 255.

Press

ENTER to accept the value. Move the pointer to

Name and press ENTER to open a field edit window and

type in a

Name for the new Device.

To delete a device from the list, simply select the desired

Device from the list box, then press Del (F4) to delete

that device from the system.
NOTE: Device and Name are fields associated with

communication through a wireless transmitter. These

fields can be ignored when using a wired connection.
Press

Prev (F2) to return to Screen 2a on page 66.

Press

New (F3) to add a new device number.

Press

Del (F4) to delete the current selected device

number.
Press

Srvr (F5) to advance to Screen 5 on page 69.

From

Screen 2a on page 66, press Port (F3) to advance

to

Screen 3 on page 68.

(2/2)

Off

Off

SETUP LCP FILE SERVER

Startup Caps Lock:

Startup Insert Flag:
FILE SERVER DEVICES

Use F3/New to specify the node

addresses used in the network.

Prev New Srvr

(2/2)

Off

Off

SETUP LCP FILE SERVER

Startup Caps Lock:

Startup Insert Flag:
FILE SERVER DEVICES

Device:

Name:

Prev New Del Srvr
