Delivery Code

Screen 24a, b, c: Delivery Code (1/4,

2/4, 3/4)

Delivery Ticket? indicates that a delivery ticket is

pending. A new delivery cannot be started until this field

is cleared by successfully printing the last delivery ticket.
Shift Ticket? indicates that a shift ticket has been

requested and is waiting to be printed.
Flow Active? indicates flow is active during a delivery.

The field is turned on and off with the

Delivery Active?

field but is also turned off when a delivery is paused and

turned back on when it is resumed.
Delivery Active? indicates that a delivery is active. The

field is turned on just before the

Delivery Beginning? field

is turned off and is turned off at the end of the delivery.
Gross Preset Active? indicates the current delivery is

delivering a gross preset quantity. When this quantity is

reached the delivery will either end or pause depending

on the type of preset being run.
Net Preset Active? indicates the current delivery is

delivering a net preset quantity. When this quantity is

reached the delivery will either end or pause depending

on the type of preset being run.
Stop/Gross Preset? indicates the current delivery has

been stopped due to the gross preset value being reached.

Depending on the type of preset being run, the delivery

will either terminate or pause.
Stop/Net Preset? indicates the current delivery has

been stopped due to the net preset value being reached.

Depending on the type of preset being run, the delivery

will either terminate or pause.
VCF Active? indicates that the current product will be

temperature volume compensated during delivery.
S1 Closed? indicates the status of the S1 solenoid. This

is

No at the beginning of a delivery and Yes when solenoid

1 is closed due to the remaining gross or net preset value

being less than or equal to the value in the

S1 Close field.

See page 32 for a discussion of the

S1 Close field.

Delivery Beginning? indicates that a delivery is in the

process of being started. Once the delivery has been

started successfully, this field is turned off.
New Delivery Queued? indicates that a new delivery has

been queued in the LCR. This condition occurs when a

Run command is issued and the switch is in the STOP,

PRINT, or SHIFT PRINT position.
Press

Next (F1) to advance to Screen 24d on page 64.
