Product Calibration

Screen 10e: Product Calibration (5/6)

Aux Multiplier is used to convert quantity delivered to

an alternate volume or inferred mass. In order for this to

be valid, the operator must furnish applicable conversion

factor. For example: To convert from

GALLONS of water

to

LBS of water, the Aux Multiplier value is 8.345.

Press

ENTER to open a field edit window and enter a

value between

0.000 and 9999.999. If this value is set

to “

0”, the AUX MULT value will NOT print on delivery

ticket.
Aux Quantity is not an editable field. It represents current

quantity of

Aux Units for current delivery.

Aux Units is the auxiliary unit of measure that will print

on the delivery ticket. Press

ENTER to open a list box

window with the following options:

Gallons

Litres

Cubic M

LBS

KGS

Barrels

Other

Move pointer to desired value and press

ENTER. This

selection, as well as

Aux Quantity will print on the delivery

ticket.
Gross Totalizer is the amount of non-temperature

compensated product that has passed through the

meter.
Net Totalizer is the amount of temperature compensated

product passed through the meter.
Press

Next (F1) to advance to Screen 10f on page 43.

(5/6) 1

Units: Gallons

0.000

0.0

Other

899.3

877.1

PRODUCT CALIBRATION

Product #: 1

Aux Multiplier:

Aux Quantity:

Aux Units:

Gross Totalizer:

Net Totalizer:

Next Prev Cnfg Main
