Configure lcr, Screen 7: configure lcr – Liquid Controls DMS Setup User Manual
Page 28

28
Network and LCR Device must be assigned first.
Configure LCR is similar to Main Menu as a launching
point for several other sub-menus. Within
Configure
LCR are:
General Setup
Advances display to
Screen 8a on page 29.
System Calibration
Advances display to
Screen 9a on page 32.
Product Calibration
Advances display to
Screen 10a on page 37.
Diagnostics
Advances display to
Screen 11a on page 48.
Security
Advances display to
Screen 12 on page 49.
Pressing
Stat (F3) advances display to Screen 21 on
page 60.
Pressing
LCR# (F4) allows the operator to select the
LectroCount register to be configured.
Pressing
Main (F5) returns display to Screen 2 on page
20.
Ensure pointer is on
General Setup and press ENTER
to advance to
Screen 8a on page 29.
Screen 7: Configure LCR
Configure LCR
1
CONFIGURE LCR
General Setup
System Calibration
Product Calibration
Diagnostics
Security
Status LCR# Main
