Screen 21: Machine Status

Machine Status

The Machine Status screens contain many indicators of

current system conditions. From this screen the operator

can access printer status, delivery status, and delivery

code information.
State indicates the current state of the LCR. It will display

one of the following indicators:

Run

Stop

End Delivery

Auxiliary

Shift

Calibrate

Waiting for No-Flow

Unknown

Printing? indicates whether or not the attached printer is

currently printing text. This will either be

Yes or No.

Other Errors indicates if there are any other errors being

reported by the LCR. This will either be

Yes or No.

Press

Diag (F1) open a list box window with the options

Yes and No. Select “Yes” to print a diagnostic ticket.
Move the pointer to:
Printer Status and press ENTER to advance to Screen

22a on page 61.
Delivery Status and press ENTER to advance to Screen

23a on page 62.
Delivery Code and press ENTER to advance to Screen

24a on page 63.

(1/2) 1

Unlocked Idle

Shift Print

Waiting for No-Flow

No

Yes

MACHINE STATUS

Security:

Switch:

State:

Printing?

Other Errors?

Next Diag LCR# Exit

(2/2) 1

MACHINE STATUS
Printer Status

Delivery Status

Delivery Code

Prev Diag LCR#
