47

Multi-Point Calibration

13. Move pointer to

Flow Rate and press ENTER to open

a field edit window and enter the maximum flow rate

observed during the run. Press

ENTER.

14. Continue proving at various flow rates using additional

Point Numbers and repeat procedure (return to Step

8) for each additional number. A minimum of three

points is recommended (high, medium, and low flow

rates) to obtain a good fit to the meter’s curve.

All ten points can be used to obtain optimum results.

Any unused points should be left at “

0.00” for Flow

Rate and 0.000 for Percent Error.

15. When all the required points have been calibrated,

move pointer to

Linearization Mode and press

ENTER to open a list box window and select Applied.

This puts Linearization algorithm into effect. If the

error message

ADJACENT POINTS OUT OF 0.25%

RANGE is displayed, Applied function will not take

effect and more points will need to be added to ensure

that no two adjacent points, based on flow rate, are

more than 0.25% apart in their corresponding

Percent

Error fields.

When Linearization is complete, press

Cnfg (F4) to return

to

Screen 7 on page 28, or press Main (F5) to return to

Screen 2 on page 20.
From

Screen 7, move pointer to Diagnostics and press

ENTER to advance to Screen 11a on page 48.

(6/6) 1

Units: Gallons

Setup

PRODUCT CALIBRATION

Product #: 1

Linearization Mode:

Pointer Number:

Flow Rate:

Percent Error:

Prover Quantity:

Prev Cnfg Main

Method 2 - Continued
