General Setup
Screen 8c: General Setup (3/5)
The next three consecutive screens all deal with header
information to be printed on a delivery ticket. The header
lines are edited individually. Press ENTER to open a field
edit window for each line. Enter alpha-numeric information
up to 35 characters in length per line. Any or all of these
fields may be left blank.
NOTE: Since display is set to 30 character width, header
text information may scroll off the screen. This will be
indicated by ›› at the end of the header text line. All
information will, however, print on the delivery ticket.
Screen 8d: General Setup (4/5)
Header lines 6 through 10. Refer to description above.
Screen 8e: General Setup (5/5)
Header lines 11 and 12 print conditionally. Header line
11 prints only if Aux1 is set to ON DURING DELIVERY.
Similarly, Header line 12 prints only if Aux2 is set to ON
DURING DELIVERY. For example, if an additive injector
is activated by Aux1, it may be desirable to note this on
the ticket by adding a header line such as “ Prist added
to this delivery”.
Press
Cnfg (F4) to return to Screen 7 on page 28. Move
the pointer to System Calibration and press ENTER to
advance to Screen 9a on page 32.
(5/5) 1 GENERAL SETUP
Header Text
11:
12:
Prev Cnfg Main
(3/5) 1 GENERAL SETUP
Header Text
1:
2:
3:
4:
5:
Next Prev Cnfg Main
(4/5) 1 GENERAL SETUP
Header Text
6:
7:
8:
9:
10:
Next Prev Cnfg Main
