14
System Utilities
Screen 2b: System Utilities (2/3)
Startup Caps Lock is used to designate whether the DMS
i1000Menu should boot with caps lock on or off. Press
ENTER to open a list box window with options Off or On.
Startup Insert Flag is used to designate whether the DMS
i1000Menu should boot with the system set to insert or
overwrite. Press ENTER to open a list box window with
options Off or On.
Office Node Address allows operator to specify LCP node
address used by an office computer when communicating
with a wireless transmitter. This can be any number in the
range from 0 to 255. Leave this set to 0.
Office Path is used to identify a path to where transaction
and database files are located on an office computer
when a wireless transmitter is in use. This can be an
alpha-numeric string up to 244 characters in length. As
an example:
C:\ or
C:\DMS i1000 or
C:\DMS i1000\DATA or
C:\SOURCE\DMS i1000
Leave this field blank.
USB Path is used to identify path to where transaction
and data base files are located on the DMS i1000 USB
flash memory. This field can be an alpha-numeric string
up to 244 characters in length. As an example:
D:\ or
D:\DMS i1000 or
D:\DMS i1000\DATA
Press Next (F1) to advance to Screen 2c on page 15.
Press Prev (F2) to return to Screen 2a on page 13.
Press Exit (F5) to exit System Utilities menu and advance
to Screen 3 on page 16. Screen 1 may not appear again
during normal operation.
(2/3)
Off
Off
255
C:\SOURCE\DMS i1000
D:\DMS i1000
SYSTEM UTILITIES
Startup Caps Lock:
Startup Insert Flag:
Office Node Address:
Office Path:
USB Path:
Next Prev Exit
