Screen 19a: Preset and Delivery (1/7)
Preset and Delivery
When power is applied to the LectroCount DMS i1000, the
system runs diagnostics internally. If the system detects
the LCRConfg.slf file does not exist, Screen 1 on page 19
will be displayed. If the LCRConfg.slf file does exist, the
display will advance to the first of the Preset and Delivery
screens as shown to the right.
The first line displays the active
Product # and its unit
of measure. The unit of measure was defined in System
Calibration and cannot be changed from this screen. The
Product # can be changed by positioning the pointer on
Product # and pressing the ENTER key. This opens a
list box window which will contain the product numbers of
all calibrated products. Select desired product number to
be delivered and press ENTER.
The next three items are preset values. A preset
delivery can be made based on Price, Net volume, or
Gross volume. The column under Delivery displays last
delivered values for each.
Price is used to set a preset delivery based on total
price. Move pointer to Price and press ENTER to open
a field edit window. Enter a value representing the total
price for the delivery, for example, 200.00 dollars. The
delivery will automatically end when this value, or a value
near this (without exceeding it), is reached. The value
may not be exactly 200.00 as the volume delivered may
not translate exactly to 200.00. For instance, a preset of
200.00 is entered and the price per unit volume is 1.27.
This would result in a Gross volume delivery of $200.00
÷ $1.27 = 157.48031. If the decimal setting is whole, this
will show up as 157. This then results in a delivery of 157
x $1.27 = $199.39.
Net and Gross are both preset deliveries based on
volume (as apposed to price). If the preset delivery is a
temperature compensated delivery, use Net for the preset
delivery. If the delivery is not temperature compensated,
use Gross for the preset delivery.
Move pointer to either Net or Gross and press ENTER to
open a field edit window. This preset value can have
the following range based on the decimal setting:
Decimal Setting Range
Whole 0 to 10,000,000
Tenths 0.0 to 1,000,000.0
Hundreths 0.00 to 100,000.00
Enter desired value and press ENTER to accept.
Preset Type defines how preset values are handled after
a delivery is complete. Move pointer to Preset Type and
press ENTER to open a list box window with the following
options:
Clear: This option clears the preset value after a delivery.
This requires the operator to enter a preset amount
prior to each delivery where a preset delivery is
desired.
Multiple: This option pauses the delivery when the preset
value is reached. The delivery can then be continued
by the same preset amount when it will pause again.
When the delivery is completed, the preset amount will
clear. If the No-Flow Timer times out during a pause,
the delivery will end and a ticket will print out.
Inventory: This option is similar to the Multiple option with
the exception that the preset value is not reset to the
original value when the pause occurs. This option is
typically used to monitor the inventory on the delivery
vehicle. The delivery can then be ended by pushing
the PRINT/END key on the DMS i1000 Lap Pad.
Retain: This option is similar to Clear. The delivery
ends when the preset value is reached, however,
the preset value is not cleared. For instance, if a
Gross preset is set to 100 gallons, it will reset to 100
gallons at the end of each delivery, until it is changed
by the operator. The retain value will reflect the last
programmed preset value.
Press Next (F1) to advance to Screen 19b on page 55.
Press Stat (F3) to advance to Screen 21 on page 60.
Press LCR# (F4) to select a different LCR for the
delivery.
Press
Main (F5) to return to Screen 2 on page 20.
(1/7) 1
Units: Gallons
Delivery
0.00
47.1
48.8
Clear
PRESET AND DELIVERY
Product #: 1
Preset
Price:
Net: 0.0
Gross:
Preset Type:
Next Status LCR# Main
