Main Menu

Screen 2: Main Menu

Main Menu

is the launch point for system setup, calibration,

and configuration. Items appearing on the Main Menu

are

typically used for initial setup and configuration of the

system but may be reset should the system or application

change.
By default, the pointer position will be the first available

function on the screen. To move pointer from

Setup

Network to another line, use up or down arrow of the

DMS i1000 Lap Pad. The up arrow is on shares

T key

and down arrow shares

Y key.

Setup Network

Advances display to

Screen 3 on page 21.

System Parameters

Advances display to

Screen 6a on page 26.

Configure LCR#

Advances display to

Screen 7 on page 28.

Save Configuration

Advances display to

Screen 14 on page 51.

Load Configuration

Advances display to

Screen 15 on page 52.

Dlvy appears above function key F1. Press Dlvy (F1) to

advance to

Screen 19a on page 54.

LCR# appears above function key F4. Press LCR# (F4)

to open a list box window with options for selecting an

LCR to communicate with.
Press

Esc to exit list box window. Move pointer to Setup

Network and press ENTER to advance to Screen 3 on

page 21.

Screen 1: Program Initialization

When the LCRHost application is initialized at start-

up, screen to the right appears. This screen contains

information about the operating software. The first line

contains program name and revision.
The message shown in lines 4-7 which appear after the

introduction lines, will then appear under the following

condition:

LCRHost detects that the LCRConfg.slf file does not

exist.

If system was already configured, the display will advance

to

Screen 19a: Preset and Delivery (1/7) on page 54.

If communication cannot be established with the LCR,

then display will show

Screen 20: Device Not Found

on page 59.
If this is the initial set and configuration of the system,

press

Main (F5) to advance to Screen 2 shown below.

LCRHost v1.02
Welcome to LCRHost!
To set up your network, go to

the Main Menu by pressing the

F5/Main key.

Main

LCRHost v1.02

MAIN MENU

Setup Network

System Parameters

Configure LCR #xxx

Save Configuration

Load Configuration

Dlvy LCR#
