58

Screen 19f: Preset and Delivery (6/7)

Preset and Delivery

This screen contains information relating to the operator’s

shift. Assuming that the shift information was reset after

the last shift was completed, these values should all

initially be “

0”.

NOTE: If an operator is beginning a shift and wants shift

information available at the end, then the shift totals from a

previous shift should be cleared. This is done on

Screen

19g shown below.
Assuming that the shift totals were cleared, this screen

updates with shift information throughout the day.
Deliveries indicates the number of deliveries made.
Shift Net indicates the total temperature compensated

volume delivered during the shift.
Shift Gross indicates the total non-temperature

compensated volume delivered during the shift.
Press

Next (F1) to advance to Screen 19g shown

below.

Screen 19g: Preset and Delivery (7/7)

This screen contains the date and time that a shift began.

It also allows the operator to reset the shift totals.
Clear Shift? is used to reset the shift totals to “0”. Move

the pointer to

Clear Shift? and press ENTER to open a

list box window with the options

Yes or No. Select “Yes

to clear the shift values. Select “

No” to cancel the clear

shift command.
Press

Stat (F3) to advance to Screen 21 on page 60.

(6/7) 1

Units: Gallons

Gasoline

8

403.5

415.5

PRESET AND DELIVERY

Product #: 1

Product Type:
Deliveries:

Shift Net:

Shift Gross:

Next Prev Status LCR# Main

(7/7) 1

01/13/05 15:40:59

No

PRESET AND DELIVERY

Shift Start:
Clear Shift?

Prev Status LCR# Main
