System Calibration
Screen 9b: System Calibration (2/5)
Units of Measure is used to define base unit of measure
for delivery quantities. Press ENTER to open a list box
window with the options:
Gallons
Litres
Cubic M
LBS
KGS
Barrels
Other
Move pointer to selection and press ENTER.
Flow Rate Base is used to define rate base used by flow
rate field. Press ENTER to open a list box window with
the options:
Per Hour
Per Minute
Per Second
Move pointer to desired option and press ENTER.
Decimals is used to define the number of digits maintained
to right of decimal point in quantity fields. Press ENTER
to open a list box window with the options:
Hundredths = 2 decimal places (e.g. 120.22)
Tenths = 1 decimal place (e.g. 120.2)
Whole = 0 decimal places (e.g. 120)
Move pointer to desired option and press ENTER.
Residual Processing is used to define what happens
with residual amounts. Press ENTER to open a list box
window with the options:
Round
Truncate
Selecting Round causes quantity residuals to be rounded
in the displayed values. Selecting Truncate causes
quantity residuals to be truncated from the display values.
For example, if actual quantity registered is 100.26 and
Decimals is set to Tenths, the Round value would be
100.3, and Truncated value would be 100.2.
Press Next (F1) to advance to Screen 9c on page 34.
