Screen 9c: System Calibration (3/5)
System Calibration
The first three items on this screen are used to define
parameters of an odometer sensing device (if installed
as part of the LCR).
The fields of
Pulses/Distance, Calibrated Distance, and
Odometer are used to calibrate an odometer pulser if an
odometer input is being used with an LCR.
NOTE: LectroCount LCR-II does not have an odometer
input option. If the register is required to maintain an
odometer reading, use LectroCount LCR.
Pulses/Distance represents number of pulses from an
odometer pulser the LectroCount LCR counts per unit of
distance (miles or kilometers). For initial calibration of the
odometer, enter 4000 as a starting point. The frequency
of the odometer pulser must be no more than 25 pulses
per second or inaccuracies will result.
If odometer feature is not being used, this number must
be set to 2.
If LCR odometer input terminals are being used for
optional START/STOP feature, Pulses/Distance must
be set to “ 0”.
Calibrated Distance is used to calibrate the odometer.
To begin odometer calibration, enter “ 0” for Calibrated
Distance. Drive vehicle a known distance (minimum of 5
miles recommended) using truck’s odometer for reference.
Enter actual distance traveled in the Calibrated Distance
field. This will automatically adjust Pulses/Distance to
reflect corrected number.
Odometer represents truck’s odometer once odometer
function has been calibrated.
Enter truck’s current odometer reading in
Odometer field
edit window. Press ENTER to accept value.
NOTE: The next two fields will only be displayed when a
LectroCount register has software SR216 installed.
Password Usage is used to determine when a password
will be required on front panel of the LCR-II. Press ENTER
to open a list box window with the options:
Delivery
None
Shift
Select None to indicate password field will not be used.
Select Delivery to specify password will need to be
entered before each delivery.
Select
Shift to specify password will need to be entered
before each shift.
Customer Usage allows operator to specify when
customer number will be required on the front panel of
the LCR-II. Press ENTER to open a list box window with
the options:
Delivery
None
Select None to indicate customer number will not be
required and will be set to 0 for each delivery.
Select Delivery to indicate customer number will be
required for each delivery.
Press
Next (F1) to advance to Screen 9d on page 35.
