24

Setup Network

Setting up network port sets up communication parameters

between LectroCount DMS i1000 and LectroCount

electronic register.
Port is used to select the port and interrupt request line

used by the active network. Press

ENTER to open a list

box window for

Communications Port. The following

options will be available:

COM1

COM2

COM3

COM4

Use Base Address of UART

A standard DMS i1000 Module is wired to communicate

with the LCR network on COM2, IRQ3, at a baud rate of

19200, therefore select

COM2 and press ENTER. This will

open another list box window. The new list box window is

for selecting the

IRQ used by the port. This list box window

contains interrupt request (IRQ) values between

2 and 15.

Select IRQ “

3” and press ENTER to accept the COM and

IRQ choices and return to

SETUP NETWORK PORT.

The changes for

Port are now displayed on the screen.

Move pointer to

Bits/Second (baud rate) and press

ENTER. This opens the Bits/Second list box window.

This value is the baud rate used to communicate with the

network of LectroCount registers. The following options

are available:

2400

4800

9600

19200

57600

It is recommended to use a baud rate of

19200. Select

19200 and press ENTER to accept the value. If there is

no printer connected to the system, a baud rate of

57600

can be selected.

Screen 5: Setup Network Port

COM2 using IRQ 3

19200

RTS

1

100

Yes

SETUP NETWORK PORT

Port:

Bits/Second (Baud):

Tx Enable Bit:

Maximum Retries:

Timeout (ms):

Baud Synchronization :

Exit

IRQ

3

4

5

6

7

8

Home PgUp Find PdDn End

SETUP NETWORK PORT

Bits/Second

2400

4800

9600

19200

57600

SETUP NETWORK PORT

Communications Port

COM1

COM2

COM3

COM4

Use Base Address of UART
