26
Screen 6a: System Parameters (1/2)
System Parameters screens are used to set up user
interface and system information.
Move pointer to
Language and press ENTER to open a
list box window of languages. Select desired language
to be used by LCRhost and displayed on the DMS i1000
Lap Pad. Language options currently include English.
Move pointer to LCRHost Password and press ENTER
to open a field edit window. Enter an alpha-numeric code
up to 10 characters in length. Once LCRHost Password
is entered, the operator is required to enter this code in
effort to access the Main Menu from delivery screens.
NOTE: If password protection of Main Menu is not
desired, leave this field blank.
The fields are for setting date and time of LCRHost
processor (not the LCR). Date and time are field edit
windows. Enter current date and time for each field.
Date/Time Master designates which device will have the
master copy of the date and time. When a new delivery
is started, date and time from the master device will
be sent to a slave device. Move pointer to Date/Time
Master and press ENTER to open a list box window with
the options:
HOST
LCR
None
If HOST is selected, date and time are maintained in the
LCRHost processor. When a delivery is started, HOST
date and time will be sent to the LCR. If LCR is selected,
date and time are maintained in the active LCR to be
retrieved and set in the LCRHost processor at start of
each delivery.
If
None is selected, then date and time will not be
synchronized between LCRHost processor and active
LCR. Date and time information appearing on delivery
ticket will be from the LCR.
Press
Next (F1) to advance to Screen 6b on page 27.
Press Vers (F4) to open DMS i1000 About Display shown
on the bottom of page 12.
System Parameters
(1/2)
English
01/16/06
16:00:23
Host
SYSTEM PARAMETERS
Language:
LCRHost Password:
Host Date:
Host Time:
Date/Time Master:
Next Vers Main
