52
Screen 15: Load Configuration
Load Configuration
The Load Configuration feature loads a LectroCount with
calibration data previously saved with Save Configuration
option.
Press
ENTER to open a list box window which contains a
list of all previously saved configurations. Select desired
Input File and press ENTER. After the Input File has been
selected, press Load (F1) to load the configuration data to
the LectroCount. When Load is selected, the system will
prompt the operator with the a list box window that asks
if the current file should be overwritten with the selected
Input File. Select Yes or No and press ENTER.
NOTE: For this function to be implemented, the
LectroCount register must be in calibration mode.
1 LOAD CONFIGURATION
Use the field below to select
the input file that contains
the configuration data that is
to be sent to the LCR.
Input File:
Load LCR# Main
