Setup Network Devices
(3/3)
1|1-METER SYSTEM
SETUP NETWORK
Network:
Last Device:
Prev Addr Srch Setup
Finding active device
Last Device:
Prev Addr Srch Setup
The setup process has
completed successfully.
LCRHost: 31025
Press ENTER to proceed.
(3/3)
1|1-METER SYSTEM
1
1
SETUP NETWORK
Network:
======SEARCH FOR DEVICES======
First Device:
Last Device:
Prev Addr Srch Setup
(3/3)
1|1-METER SYSTEM
SETUP NETWORK
Network:
Set Up LCR Devices
No
Yes
Move pointer to Last Device and enter Setup (F5) this
allows automatic selection of an active LCR device.
Under Set Up LCR Devices, move pointer to
Yes then
press ENTER. This will display The setup process has
completed successfully.
When a new device is found, enter a name for it and
continue with setup.
To remove a device from the network configuration, select
device and press Del (F4). This deletes the selected
device. Deleting a device connected to the network
will cause it’s node address to be reset to 250. When
programming of network devices is complete, press Exit
( F5) to return to Screen 4a on page 21. Then press Main
( F5) to return to Screen 2 on page 20.
Move pointer to System Parameters and press ENTER
to advance to Screen 6a on page 26.
NOTE: It will be assumed the operator can now
readily navigate list box windows and field edit
windows. Therefore, these windows will no
longer be shown for remainder of this manual.
Screen 4c: Setup Network (3/3)
