Spring-loaded terminals for wire cross-section
-
Massive wire, cord 0.2 … 2.5 mm² (AWG 24 … 14)
-
Stranded wire with end sleeve 0.2 … 1.5 mm² (AWG 24 … 16)
Indicating and adjustment module
Voltage supply and data transmission through the sensor
Indication LC display in dot matrix
Measured value indication
-
Number of digits 5
-
Size of digits W x H = 7 x 13 mm (sensors with software ≥ 4.0.0,
hardware ≥ 2.0.0)
W x H = 5 x 8 mm (sensors with software ≤ 3.99,
hardware < 2.0.0)
Adjustment elements 4 keys
Protection rating
-
unassembled IP 20
-
mounted into the sensor without cover IP 40
Materials
-
Housing ABS
-
Inspection window Polyester foil
Integrated clock
Date format Day.Month.Year
Time format 12 h/24 h
Time zone Ex factory CET
Measurement electronics temerature
Resolution 1 °C (1.8 °F)
Accuracy ±1 ° C (1.8 °F)
Voltage supply
Operating voltage
-
Non-Ex instrument 9.6 … 36 V DC
-
Ex-ia instrument 9.6 … 30 V DC
Operating voltage with illuminated indicating and adjustment module
-
Non-Ex instrument 16 … 36 V DC
-
Ex-ia instrument 16 … 30 V DC
Interpolation protection Available
Permissible residual ripple - Non-Ex, Ex-ia instrument
-
for 9.6 V
< U
N
< 14 V ≤ 0 .7 V
eff
(16 … 400 Hz)
-
for 18 V
< U
N
< 36 V ≤ 1 .0 V
eff
(16 … 400 Hz)
LEVEL TRANSMITTER 8136 • 4 … 20 mA/HART - two-wire 65
11 Supplement
