Signal resolution 0.3 µA
Failure signal current output (adjustable) mA-value unchanged 20.5 mA, 22 mA, < 3.6 mA
Max. output current 22 mA
Starting current ≤ 3 .6 mA; ≤ 10 mA for 5 ms after switching on
Load see load diagram under Power supply
Damping (63 % of the input variable),
adjustable 0 … 999 s
HART output values according to HART 7.0 1)
-
PV (Primary Value) Distance to the level
-
SV (Secondary Value) Level as percentage value
-
TV (Third Value) Linearised percentage value
-
QV (Fourth Value) Scaled measured value
Resolution, digital < 1 mm (0.039 in)
Accuracy (according to DIN EN 60770-1)
Process reference conditions according to DIN EN 61298-1
-
Temperature +18 … +30 °C (+64 … +86 °F)
-
Relative humidity 45 … 75 %
-
Air pressure 860 … 1060 mbar/86 … 106 kPa (12.5 … 15.4 psig)
Installation reference conditions
-
Min. distance to installations > 200 mm (7.874 in)
-
Reflector Corner reflector
-
False reflections Largest false echo 20 dB smaller than the useful
echo
Deviation with liquids See following diagrams
1) Default values, can be assigned individually
