Vessel pressure
-
Encapsulated antenna system
-1 … 3 bar (-100 … 300 kPa/ -14.5 … 43.5 psi)
-
Plastic horn antenna
-1 … 2 bar (-100 … 200 kPa/-14.5 … 29.0 psig)
-
Version with adapter flange from DN 150
PP
-1 … 1 bar (-100 … 100 kPa/-14.5 … 14.5 psig)
Process temperature (measured on the
process fitting)
-40 … +80 °C (-40 … +176 °F)
Vibration resistance
-
With adapter flange
2 g at 5 … 200 Hz according to EN60068-2-6
(vibration with resonance)
-
with mounting strap
1 g at 5 … 200 Hz according to EN60068-2-6
(vibration with resonance)
Shock resistance
100 g, 6 ms according to EN60068-2-27 (mechan-
ical shock)
Electromechanical data - version IP 66/IP 67 and IP 66/IP 68; 0.2 bar
Cable entry/plug
5)
-
Single chamber housing
l
1 x cable gland M20 x 1.5 (cable: ø 5 … 9 mm),
1 x blind stopper M20 x 1.5
or:
l
1 x closing cap M20 x 1.5; 1 x blind stopper
M20 x 1.5
or:
l
1 x closing cap ½ NPT, 1 x blind plug ½ NPT
or:
l
1 x plug (depending on the version), 1 x blind
stopper M20 x 1.5
-
Double chamber housing
l
1 x cable entry M20 x 1.5 (cable: ø 5 … 9 mm),
1 x blind stopper M20 x 1.5; 1 x blind stopper
M16 x 1.5 or optional
6)
1 x plug M12 x 1 for
external indicating and adjustment unit
or:
l
1 x closing cap ½ NPT, 1 x blind stopper
½
NPT, 1 x blind stopper M16 x 1.5 or
optionally
7)
1 x plug M12 x 1 for external
indicating and adjustment unit
or:
l
1 x plug (depending on the version), 1 x blind
stopper M20 x 1.5; 1 x blind stopper M16 x 1.5
or optionally
8)
1 x plug M12 x 1 for external
indicating and adjustment unit
5)
Depending on the version M12 x 1, according to ISO 4400, Harting, 7/8" FF.
6)
Only with Ex d version
7)
Only with Ex d version
8)
Only with Ex d version
