2002-12-11 66
XT Locating station XTPX P11 A
XT Lift & Locate station XTPX P12
Symptom Possible cause Action Reference If fault remains
Jam and noise when
lifting, lowering the
pallet
Worn guide pins Replace guide pins “Check wear of guide
pins” on page 11
Contact your local
FlexLink supplier
Incorrect orientation
of non-cylindric
guide pin Rotate pin to correct
orientation “Assembly manual
XT modules”
Incorrect position of
lift units Correct distance
between units to fit
the pallet bushings “Check docking of
pallet” on page 11
Incorrect position of
stop Adjust placement of
stop to fit the locating
unit
Incorrectly adjusted
pneumatic throttle
valves Adjust pneumatic
throttle valves “Check speed of lift
and lowering
movement” on
page 11
Symptom Possible cause Action Reference If fault remains
Jam and noise when
lifting, lowering the
pallet
Worn guide pins Replace guide pins “Check wear of guide
pins” on page 12
Contact your local
FlexLink supplier
Incorrect orientation
of non-cylindric
guide pin Rotate pin to correct
orientation “Assembly manual
XT modules”
Incorrectly
positioned stop Adjust placement of
stop to fit the locating
unit
Incorrectly adjusted
pneumatic throttle
valves Adjust pneumatic
throttle valves “Check speed of lift
and lowering
movement” on
page 12
