3 Remove the slide rail that shall be replaced.
4 Mark up all old rivet holes at the bottom of the
beam with a marker.
5 Chamfer the top and side faces on the slide rail
(compare/copy old slide rail).
6 Mount the slide rail, make sure to not fit it upside
down. Leave a 4 mm distance in the joint
between two slide rails.
