2002-12-11

Replace motor on XT Compact conveyor module

Introduction

Valid for XT Compact conveyor only.

Tools

Instruction

Box wrench

10 mm

Box wrench

8 mm

Allen key

5 mm

1 Remove the screws on the driving belt cover.

Use the 8 mm box wrench.

2 Remove the driving belt cover.
