2002-12-11 53
7 Loosen two screws holding the side cover (one
side only), use a 10 mm box wrench. Remove
the side cover.
8 Remove the screw holding the beam using a
5 mm Allen key.
Remove the two screws holding the beam on the
other side using the 8 mm box wrench.
9 Rotate the beam 90º around the shaft and
replace the driving belt.
Rotate the beam back 90º.
10 Fit the screw holding the beam using a 5 mm
Allen key.
Fit the two screws holding the beam on the other
side using the 8 mm box wrench.
