2002-12-11 65
XT Transfer unit XTPT PWxPL
Symptom Possible cause Action Reference If fault remains
Jerky movment of
conveyor
Noisy conveyor
Worn or damaged
conveyor links Replace links or
chain “Check wear or
damage of conveyor
chain” on page 10
Contact your local
FlexLink supplier
Conveyor chain too
loose Shorten conveyor
chain Compare “Check
elongation of
conveyor chain (only
valid for conveyor >
1500 mm)” on
page 6
Damaged or
deformed slide rail Replace slide rail Compare “Check the
slide rails” on page 6
Wrong driving belt Replace driving belt “Replace driving belt
on XT transfer unit
XTPT M1” on
page 51 or “Replace
driving belt on XT
transfer unit XTPT
M2” on page 56
Damaged motor Replace motor “Replace motor on
XT transfer unit
XTPT M1” on
page 47 or “Replace
motor on XT transfer
unit XTPT M2” on
page 48
Incorrectly
connected electrical
cables Check wiring
diagram “Assembly manual
XT modules”
Damaged or
incorrectly
connected capacitor Check wiring
diagram.
Check capacitor “Assembly manual
XT modules”
Pallet jam during
cross transport
Incorrectly height
adjusted transfer
station in relation to
connecting cross
conveyor Adjust level of upper
position of transfer
station to be in line
with connecting
cross conveyor “Check speed of lift
and lowering
movement” on
page 10
Jerky movement
when lifting, lowering
the pallet
Noisy when lifting,
lowering the pallet Incorrectly adjusted
pneumatic throttle
valves Adjust pneumatic
throttle valves “Check speed of lift
and lowering
movement” on
page 10
