INPUTS/OUTPUTS
General
The DXN is comes with a variety of input and output options. The individual I/O connections are accessed by using the
included Breakout Box connected to the DXN via a DB15 cable connection. This connection is labeled Process I/O.
I/O Connection
Figure 110: Display I/O Connection
To DXN
DB15
Interconnect
Cable
Figure 111: Breakout Box
