Storage
Site Name 0.00 GPM
3/28/2012
13:24
System Site I/O Cal Adv Display Meter Log
Storage Comm Update PC ENet Disk Power Time Misc
Rename Site Copy Site To USB
Select Site to Manage
Unlock Logs Delete Delete Site Logs
Unlock Site Delete Delete Site
Figure 105: System Storage
The selections in the System>Storage page lets you manage the sites stored in the DXN memory.
First for any site to be worked on it must be selected. Use the Select Site to Manage to choose the site to be modified or
deleted. Once the site is selected several actions become available.
Copy Site To USB
Copies all of the files associated with the selected site to a USB device connected to the USB port on the meter.
Rename Site
Lets you change the site name.
Delete Site Logs
To delete the site logs, place a check mark in the Unlock Logs Delete box. The Delete Site Logs button turns red. Press Delete
Site Logs to delete all the logs for the site chosen in the Select Site To Manage control.
Delete Site
The Delete Site control is similar to the Delete Site Logs except it deletes both the site logs and the site itself. As with the Delete
Site Logs, a check mark must be placed in the Unlock Site Delete to activate the Delete Site button. When activated, the button
turns red to warn that the entire site is about to be deleted. Once pressed the site and the site logs will be deleted from the
DXN memory space.
