SITE GROUP
Meter Adv Cal System Display Log I/O Site
Doppler Liner Pipe Lookup Transit Fluid Create Doppler Liner Pipe Lookup Transit Fluid Create
Figure 51: Site Group
The Site group is used to create and store individual metering locations. Each new location can be stored with all the setup
parameters for that particular site making periodic measurements less time consuming.
New sites can be created in two different ways. A site can be created using the factory default settings or the settings the
meter is currently using. In either case settings can be changed for that particular site whenever necessary.
Create Page
Site Name 0.00 GPM
3/28/2012
13:24
Meter Adv Cal System Display Log I/O Site
Create Doppler Liner Pipe Lookup Transit Fluid
Site Name
Entry Units English
Create New Site From
CURRENT Settings
Create New Site From
DEFAULT Settings
Load Default Settings Unlock Load Default Settings
Figure 52: Site Page Configuration
Create New Site from DEFAULT Settings (Alphanumeric Entry)
To create a new site using the meters default settings:
1. Press the Create New Site From DEFAULT Settings button. The alphanumeric keypad displays.
2. Type in a unique name for the site and then press Create Site button.
The meters default settings will be copied from memory and stored under the new site name. The Site Name button will also
show the new site name assigned.
NOTE: N The site name is restricted to 45 characters.
Create New Site from CURRENT Settings (Alphanumeric Entry)
To create a new site using the meters current settings:
1. Press the Create New Site From CURRENT Settings button. When this button is pressed the alphanumeric keypad
displays.
2. Type in a unique name for the site and then press Create Site button.
The meters current settings will be and stored under the new site name. The Site Name button will also show the new site
name assigned.
This function is used when the meter is completely set up and operating as required. Once all parameters have been
optimized all the settings are saved under the new site name making the setup of the same site much faster in the future.
NOTE: N
The site name is restricted to 45 characters.
